R6 Sub Frame

Reply Subscribe

Thread Tools

Search this Thread

Mar 2, 2006 | 10:04 PM

#21

scootnr6

Thread Starter

Registered User

Joined: Oct 2002

Posts: 472

From: Luray,VA

scootnr6 is an unknown quantity at this point

Re: R6 Sub Frame

Quote:

Originally Posted by mista_shrpnl

yea, just weld some plate to the area that needs strengthening...

Ill try to snap a pic, the sub's back on the bike in full trim now...but Ill see what I can do

what type of metal did you use. i have a sub frame at a machine shop they want to know what kind of metal i want them to use.

Mar 5, 2006 | 08:32 AM

#22

mista_shrpnl

Registered User

Joined: May 2005

Posts: 88

From: Everett,Wa

mista_shrpnl is an unknown quantity at this point

Re: R6 Sub Frame

6061 T6 Alum.

Pricey as hell, but the strongest alum readily avail to the public...

Lucky for me I work the metal industry...

Mar 16, 2006 | 12:57 AM

#23

Kra-Z-Krs

Registered User

Joined: May 2004

Posts: 91

From: Westminster-Auburn, Mass.

Kra-Z-Krs is an unknown quantity at this point

Re: R6 Sub Frame

Quote:

Originally Posted by mista_shrpnl

The new bracing extends back 6 inches from the front mount, and adds a thickness of .38, for a total width now of little over 5/8's of an inch.

The lower edge in the pics actually dips down into the chanelling of the subframe.

Subframes holding up like a tank...

I did the same Idea with my 03 r6 and so far its in one piece. PS suport it before you scrape it. I welded my subframe in 5 spots 3 difrent times
