Yeah I got my cage!!!!! Only problem is no install instructions.. I found a post that says they take 3 hours to install on CBRWorld.net.. Could someone hook me up with instructions jkimmeljr@hotmail.com . I called Aaron from Racing 905 yesterday and emailed him.. No response as of yet and I want to install it this weekend .. Any help would be greatly appriciated.. THANKS



it took a whole 30 minutes to put mine on my f4i. just look at the cage.. its self explanitory. Hardest thing is cutting the holes in the fairing in the right spot. Just do it.



what about the weird spacers and the crush washers what order do they go in?



i kno the spacers go between the cage and the frame. on the middle mount i believe it goes washers on the bolts, then slide the bolt through the cage so the washers r on the inside of the cage. then on the outside slide that spacer on the bolt so its between the cage and frame. the front mount by the pips is simple its jsut one bolt. not sure about the rear mount tell me what you have left to work with after all that and im pretty sure i can tell you the order. jsut cant remember by my self.



Still no email or call from Aaron.. Does anyone have the instructions?? This SUCKS!



havent personally done a 905 install......but i know whats up


you need to put the side without the bar on first. just look at the mounts & the spacers should explain themselves. put the bolts in but dont make them too tight. this will give you a good idea as to where to cut the holes for the bar. cut a very small hole and then do it on the other side too. once the holes line up, gradually make them larger until you can get the side with the bar in, but without bolting it on.(just hold it up to the mounts)

now bolt on the side with the bar, but no tight. you want to connect both sides of the cage together, but not tight. now tighten up the motor mounts and the other mounts to the frame. now tighten the bolt that connects the 2 sides. make sure they are tight or you will mess up mounts when you crash.

if you need anything else, get back to me. i install cages all the time.



aaron at 905 is definately hard to get intouch with. I've been trying for 2 days now so i can talk to him about sending my cage back (got bent pretty bad).



i've never owned a 905 cage, but it's pretty much self explanitory. line the cage up and see where exactly it mounts to your frame (or subframe on certain applications)...if the fairing is in the way, shave some of it off to make room. as far as the spacers, one of 'em will probably be longer than the other...the long one goes on the right, to clear the case, or maybe that's just how they make 'em for my 636, i don't know. hope that helps a little. 3 hours???? damn, i never heard of that.



He just called me back.. I had to stalker call his @ss
He told me to talk to the girl Stephanie.. Maybe you should contact her too..



Bro - I'm down here in so cal bout 30 min from 905's shop, here's the number to the front desk (Stephanie) at 905 (619) 210-3787 just ask to speak with someone about cage instilation. They'll hook you up! you should have got some in the package though? That's wierd - anyway this should solve your problem and it shouldn't take more than 45 min your 1st time after that on and off in 10 min easy - good luck :YEAH



I finally got intouch with stephanie, then like an hour later aaron call'd me back If it starts rainin today, i'm pullin my cage and motor. So if you don't have your directions yet, i'll take some pics for ya at the mounting points.



wow...from the looks of things, it sounds like it's hard to get in touch wit 905. i did it eeeeeee-bay



no customer support tho. lol



yea i won a 905 cage off ebay for $150, but i've emailed the seller 5 times in the past week trying to find out howmuch it would cost for shipping, but i think he doesn't want to sell it cause he didn't get what he wanted out of it.
ebay seller



lol...f*ck 'em then...i guess he doesn't want your money who else is he gonna sell it 2



hell if i know... i'll just see if i can't cash in on the warranty on the cage i have now
